主要用途与间介/Purpose and introduction：

NQGF型西林瓶粉针洗烘散装轧盖标贴纸签签联动性线 由QCL系落地超音波波洗瓶机、AQMR隧洞式热气嵌套循环系统无菌恒温干燥箱、NQFGX系数控加工中心挤出机螺杆粉剂散装机、NQ-50轧盖机、NQWTB-120标贴纸签签热泵机组成，也可单机手游施用。比较适合于7-25ml品种的西林瓶粉针的制作。能顺利完成喷洒充水、超音波波粗洗、瓶侧壁水清扫清理、瓶侧壁间断再次嵌套循环系统水清扫清理、一起吹气、一起优质水清扫清理、间断再次吹气、瓶侧壁吹气、清理、加温、真空干燥无菌去热原、急冷、散装、加塞、轧盖、标贴纸签签等二十来道制作工序。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

优势特点/characteristic：

◆洗瓶机用于机械装备手夹瓶，常用几种型号规格的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶通过水蒸汽喷针往复运动监视添加图片玩法，清洁效用好，节电能源开发。并还拥有针架防运动设备，增加喷针添加图片瓶里的较准度，以减少断针这种现象会发生；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶全部整个水汽压缩空气管、喷针完全性自主分离开来，防止了双向弄脏，具有GMP规定让；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶螺栓前装个缓冲区块，有防护螺栓，减掉碎瓶效果；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶用整体布局国外进口一起带，衔接拨瓶块输料西林瓶，启动动态平衡耐用；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆烘干箱按照自动空调间歇蒸汽加热，温湿度均匀分布，环保；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆烘干箱存在防显得突然关电保养功能性。启用可靠；Mixer oven has suddenly loses power protection function. Run security;◆干燥箱可配循环系统油冷试验装置，不不足房风速，才能减少房的差压不发展的的风险下滑成果好；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆恒温干燥箱可配风压力会自动发展量调理装置可以减少房子和恒温干燥箱的风压力不发展量引起的低温段偏移量，灌装设备间洗烘间的温度升等一产品系列的大问题；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆干燥箱要设DOP检验工具主板接口(具有静压、空气流速、尘沙阿尔法粒子检验工具口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆恒温干燥箱一系列冷却段可带在线平台无菌基本功能(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆烘干箱网带可带超声刷洗涌入CIP在线播放刷洗设计；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆烘烤箱内腔室可来进行全地方、多弧度直流高压水清洗道路；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆全自动灌装机机按照國際更先进典型的装修设计概念，极具快速路度，所以分瓶明确，替换尺寸规格件简单方便；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆分开包装机通过沟通交流台达伺服伺服电机伺服电机带动分开包装罗杆拖动，装量正确；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆包装机所采用装量的的调整直接的在显示屏屏上满足；Mixer packer adopts the load adjustment directly on a touch screen;◆分开包装机必选配百级不断循环式层流罩；Mixer packer optional circulating laminar flow hood best level;◆包装机无瓶停机包装，无瓶要加塞能力。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线采取PLC总管理、交流三菱变频器、触屏屏管理能力，进行稳定的能信的。触屏屏可彰显各单机联机的进行模式，各管理点的压差、标准气压、静压、温等彰显，各电开关模式和错误码率彰显，错误码率自身检查和错误码率介绍及祛除策略。使一整个制作的时候达标定时化管理，联线兼备电气自动化均等化平衡装置，保证质量制作均等化能信的。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.据业主的必须，还可供配搭：According to the needs of customers, but also available for selection:◆欧姆龙、斯耐德、西门子、台达等牌子操控装置；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气阻力、水溫及超音波波难度、尘沙a粒子、风量迅雷在线验测、短信报警、记录查询、打印纸软件系统；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、无菌操作分隔器体统。ORABS, CRABS, aseptic isolator system.

水平数据：/technical parameters

参数 model

生产销售力production capacity

洗瓶合格品率Washing bottle percent of pass

洗瓶磨损率Washing bottle breakage

灭菌方法湿度sterilizing temperature

分开装袋计算误差The repackaging of error

加塞完成率Gasser percent of pass

气体层流整洁度Laminar air cleanliness

真空度抽速Vacuum pumping speed

电阻量 capacitance

电源线power supply

总充电Total transmission energy

外观简约时尚大小boundary dimension

7-25ML国际标准西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
